201 202 Stainless Steel Channel Bar For Shipbuilding And Chemical Industries

Ask Lasest Price
Brand Name :	TISCO,BAOSTEEL,POSCO,JISCO,LISCO
Certification :	MTC; SGS
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	250 tons per month
Delivery Time :	3-15 working days

Add to Cart

Product Details
Company Profile

201 202 Stainless Steel Channel Bar For Shipbuilding And Chemical Industries

Hot Rolled Steel Bar Stainless Steel H Channel 3 Inch Channel Steel 201 202

Steel channel is often specially formed to construct vehicle frames. It can be used for both the main frame rails and for cross members, braces or structural components like radiator supports. Steel channel prevents a vehicle from flexing too much, but still allows movement to compensate for engine torque.

Product information:

Commodity	Hot Rolled Steel Bar Stainless Steel H Channel 3 Inch Channel Steel 201 202
Grade	201 202
Brand	None
Certification	SGS,BV,IQI,TUV,ISO,etc
Thickness	3-10mm
Size	UPN30-UPN400, UPE80-UPE400,5#--40#
Length	5.8m,6m or customized length
Surface	Hot rolled,cold drawn,annealed, pickling
Standard	JIS,AISI,ASTM,GB,DIN
Delivery time	About15-30 days or based on the sales contract
MOQ	1 TON
Advanatages	Construction field, shipbuilding industry,petroleum, chemical industries, war and electricity industries,food processing and medical industry,boiler heat exchanger,machinery and hardware fields

Chemical Position:

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0.15	≤1.00	5.5～7.5	≤0.060	≤0.03	3.5～5.5	16.00～18.00	-
202	≤0.15	≤1.00	7.5～10.0	≤0.060	≤0.03	4.0～6.0	17.00～19.00	-
301	≤0.15	≤1.00	≤2.00	≤0.045	≤0.03	6.00～8.00	16.00～18.00	-
302	≤0.15	≤1.00	≤2.00	≤0.045	≤0.03	8.00～10.00	17.00～19.00	-
304	≤0.07	≤1.00	≤2.00	≤0.045	≤0.03	8.00～10.00	18.00～20.00	-
304L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	9.00～13.00	18.00～20.00	-
310S	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	19.00～22.00	24.00～26.00	-
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	10.00～14.00	16.00～18.00	2.00～3.00
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	12.00～15.00	16.00～18.00	2.00～3.00
321	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	9.00～13.00	17.00～19.00	-
410	≤0.15	≤1.00	≤1.00	≤0.040	≤0.03		11.500～13.50	-
430	≤0.12	≤1.00	≤1.00	≤0.040	≤0.03		16.00～18.00	-

Physical Property:

Grade	Tensile Strength(Mpa)	Yield Strength(Mpa)	Elongation(%)	HBW	HRB	HV
304L	≥480	≥175	≥40	≤187	≤90	≤200
304	≥520	≥205	≥40	≤187	≤90	≤200
304J1	≥450	≥155	≥40	≤187	≤90	≤200
304N1	≥550	≥275	≥35	≤217	≤95	≤200
304N2	≥690	≥345	≥35	≤248	≤100	≤260
316	≥520	≥205	≥40	≤187	≤90	≤200
316L	≥480	≥175	≥40	≤187	≤90	≤200
321	≥520	≥205	≥40	≤187	≤90	≤200
409L	≥360	≥175	≥25	≤162	≤80	≤175
410L	≥360	≥195	≥22	≤183	≤88	≤200
430	≥450	≥205	≥22	≤183	≤88	≤200
430J1L	≥390	≥205	≥22	≤192	≤90	≤200
436L	≥410	≥245	≥20	≤217	≤96	≤230
410	≥440	≥205	≥20	≤201	≤93	≤210
201	≥520	≥275	≥55	≤241	≤100	≤253
202	≥520	≥275	≥55	≤207	≤95	≤218

Brand Cross Reference Table:

GB NEW BRAND	JIS	ASTM	UNS	KS	BS EN	AS
12Cr17Mn6Ni5N	SUS201	201	S20100	STS201	1.4372	201-2
12Cr18Mn9Ni5N	SUS202	202	S20200	STS202	1.4373	-
12Cr17Ni7	SUS301	301	S30100	STS301	1.4319	301
06Cr19Ni10	SUS304	304	S30400	STS304	1.4301	304
022Cr19Ni10	SUS304L	304L	S30403	STS304L	1.4306	304L
06Cr19Ni10N	SUS304N1	304N	S30451	STS304N1	1.4315	304N1
06Cr19Ni9NbN	SUS304N2	XM21	S30452	STS304N2	-	304N2
022Cr19Ni10N	SUS304LN	304LN	S30453	STS304LN	-	304LN
10Cr18Ni12	SUS305	305	S30500	STS305	1.4303	305
06Cr23Ni13	SUS309S	309S	S30908	STS309S	1.4833	309S
06Cr25Ni20	SUS310S	310S	S31008	STS310S	1.4845	310S
06Cr17Ni12Mo2	SUS316	316	S31600	STS316	1.4401	316
06Cr17Ni12Mo2Ti	SUS316Ti	316Ti	S31635	-	1.4571	316Ti
022Cr17Ni12Mo2	SUS316L	316L	S31603	STS316L	1.4404	316L
06Cr17Ni12Mo2N	SUS316N	316N	S31651	STS316N	-	316N

Surface Finish:

Surface Finish	Definition	Application
2B	Finished by heat treatment, pickling after cold rolling. Followed by skin pass line to be more brighter and smooth surface	General application Medical instruments, Tableware
BA	Bright heat treament after cold rolling	Kitchen utensil, kitchenware, architectural
8K	A mirror-like reflective surface by polishing with finer abrasives over 800mesh	Construction, mirrors, plate sets, decoration elevators
HL	Finished by continuous linear polishing	Architectural purpose, Escalators, kitchenware, vehicles
NO.1	Finished by hot rolling, annealing and picking, characterized by white pickled surface	Chemical industry Equipment, industrail tanks
NO.4	Polishing with NO.150 to NO.180 mesh abrasives specified in JISR6001	Kitchen utensils, Building Construction, Medical equipment

Packing:

Hot Rolled Steel Bar Stainless Steel H Channel 3 Inch Channel Steel 201 202 packaging details :

1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case

The innner size container as below :

1:20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM ;
2:40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM ;
3:40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM.

Product Display:

201 202 Stainless Steel Channel Bar For Shipbuilding And Chemical Industries
